Grimmspeed Pitch Stop Mount Subaru WRX 2002-2023 / STI 2004-2021
Grimmspeed Pitch Stop Mount Subaru WRX 2002-2023 / STI 2004-2021
Fitment Information:
2002-2023 Subaru WRX
2004-2021 Subaru STI
2004-2018 Subaru Forester XT
2005-2012 Subaru Legacy GT
2005-2009 Subaru Outback
2013-2017 Subaru Crosstrek
Features:
The factory pitch stop mount is often overlooked and leaves a lot of room for improvement, both in performance and aesthetics. The OEM piece is made from flexible plastic and utilizes soft bushings, which means the engine and transmission have more room to pitch back and forth instead of staying tight during hard acceleration, braking and shifting.
The standard GrimmSpeed Pitch Stop Mount solves this issue and the Race Version takes it a step further. Just like the standard version, it's made from a single piece of billet 6061 aluminum and machined to shave off as much weight as possible, while remaining completely rigid. A heavy-duty red anodized coating is applied along with two laser-etched GrimmSpeed logos. To finish things off, extremely durable 95A-durometer urethane bushings (compared to 80A in the standard version) and stainless steel sleeves are pressed in and each unit is individually inspected and packaged. With the Race Version Pitch Stop Mount equipped, the amount of play your engine and transmission have during hard acceleration, deceleration and shifting is minimized even further, with an emphasis on aggressive and track driving.
RACE VERSION QUICK SPECS:
- 6061 Billet Aluminum - Machined for looks and weight-savings
- Red Anodized Coating - Durable coating to withstand the heat and elements; red color unique to the race version
- 95A Durameter Bushings - Even more solid than the standard version
- Reversible Design - Easy and direct install, choose which logo faces up!
- Designed, Manufactured and Assembled in the USA
INSTALLATION GUIDES:
BUSHING KITS QUICK SPECS:
- 80A or 95A Durometer Options - The 1st is designed to minimize movement without being too harsh, the 2nd is more stiff for aggressive driving/track use
- Included Grease Packet - The right grease for quiet use and easy installation
- Integrated Grease Flutes - Keeps the sleeve lubricated and protected
- Designed, Manufactured and Assembled in the USA
