P&L Motorsports Subaru EJ Top Feed Fuel Rails

The P&L Motorsports Subaru EJ Top Feed Fuel Rails are a replacement rail set which allow increased fuel flow to the injectors and through the fuel system as a whole. In addition to increasing flow, the fuel rails allow for AN fittings and lines to be used in the engine bay.

These P&L top feed fuel rails fit directly to the top feed TGV housing on the intake manifold, but will require a housing swap for any vehicle which came with side feed TGV housings from the factory. We include a 3/8″ NPT port on the underside of each rail to allow for the addition of a fuel pulse damper or a secondary fuel pressure gauge sensor.

Unlike other fuel rail kits on the market, we include -6 AN fuel line fittings at no additional cost, or -8 AN fuel line fittings for a reasonable upgrade price. We recommend adding our Fuel Pressure Regulator and Fuel Lines Kit to the rails to complete your system and make it a direct plug and play installation. Adding a set of our TGV Delete Housings can complete the install!

Features:

• Ported Rail Diameter for Increased Fuel Flow to Engine
• Designed for Optimal Fuel Delivery
• -6 AN or -8 AN Line Size Compatible
• 3/8″ NPT Underside Ports
• -8 AN Straight Cut O-Ring Rail Inlet and Outlet Ports
• Fully Ethanol (e85) Compatible
• CNC Billet Aluminum Construction
• Direct Bolt On Installation

Includes:

• One Pair of CNC Machined Top Feed Fuel Rails
• Four (4) Mounting Bolts for Installation
• Two (2) 3/8″ NPT Plugs
• Four (4) -6 AN or -8 AN Line Fittings

Applications:

• 07+ Subaru STI
• 04-06 Subaru STI (Requires Top Feed TGV Housings)
• 02-14 Subaru WRX

Designed, Machined, and Assembled in the USA
